iSM-IMX317

The iENSO iSM-IMX317 is the quality leader MIPI sensor module that adapt to iENSO’s embedded ecosystem of SOMs, camera modules, and wireless connectivity modules.

The iSM-IMX317 uses SONY’s IMX317 sensor, with HDR and advanced backside-illuminated structure, to reach high sensitivity and realize high quality.

The SONY IMX317 sensor features a type 1/2.5” color CMOS with 8.3M effective pixel to achieve true 4K UHD resolution with digital overlap HDR technology and it’s suitable for various iENSO lens types.

Suggested next generation sensor module: iSM-IMX415

Attributes:

Partner

Sony

Shutter Type

Rolling

Max. Resolution (MP)

8

Optical Format (inch)

1/2.5

Pixel Size (µm)

1.62 x 1.62

Frame Rate (max.)

60fps 10bit / 30fps 12bit

HDR

Digital overlap supported

Key Specifications:

  • Framerate: 32.8 fps 4K UHD at 12 bits (62.5 fps at 10 bits) over 4-lane MIPI CSI-2 10/12-bit interface.
  • Pixel details: 1.62 μm, 3840 x 2160 array (16:9), Exmor R / STARVIS BSI, DOL-HDR, rolling shutter.
  • Package/Environmental: ceramic LGA with 92 pins
  • Operating temperature: -10°C to 60°C sensor ambient .
